Rivetless Chain

Tow Line Conveyor

Track : ISMC 100 X 50 x 5 mm thick

Chain :

Type : X458 Rivet less chain.

Pitch : 102.1mm.

Pin diameter : 5/8 “inch.

Ultimate strength: 27000 kg.

Chain trolley :
Chain trolley brackets are forged section fitted with two wheel duly grease packed. Wheels are sealed to avoid dust depositing on the bearing surface. Trollies are with pusher dog.
